| Brand | Dahua |
| Type | PoE Ethernet switch |
| Model | DH-PFS3005-4P-58 |
| Technical Specification | |
| Ethernet Port | 1*10/100 Base-T, 4*10/100 Base-T (PoE power supply) |
| PoE Power Consumption | Each power ≤30W, Total≤58W |
| PoE Protocol | IEEE802.3af, IEEE802.3at |
| Switching Capacity | 1Gbps |
| Packet Forwarding Rate | 744Kpps |
| Packet Buffer Memory | 448Kb |
| MAC Table Size | 1K |
| Flow Control | Enable |
| Application Humidity | 10%~90% |
| Power | Default DC51V/1.25A power adapter |
| Lightning Protection | |
| Common Mode | 2KV |
| Differential Mode | 1KV |
| Working Temperature | -10°C~50°C |
| Weight | 259g |
| Dimension(W×D×H) | 100mm×100mm×26mm |
| Warranty | 1 Year |
- Two-layer PoE Ethernet switch.
- MAC auto study and aging, MAC address list capacity is 1K.
- Conform IEEE802.3, IEEE802.3u and IEEE802.3X standards.
- Default Mode: The device works as a general switch and all ports support 10/100Mbps auto-negotiation.
- Extend Mode: VLAN isolation is enabled. Ports 1-4 will be isolated respectively (10Mbps auto-negotiation), but they can communicate with the Uplink port. Besides, the transmission distance of power and network data is up to 250m.
