Brand | Hikvision |
Type | POE Switch |
Model | DS-3E0105P |
Hardware Features | |
Dimensions (L x W x H ) | 105 mm × 27.6 mm × 83.1 mm |
Power Supply | |
Maximum Power Consumption | PoE on <br>263.9 W/100 V<br> 247.4 W/240 V <br> PoE off<br> 30.6 W/100 V <br>28.1 W/240 V |
Standby Power Consumption | 19.6 W/100V / 16.6 W/240V |
Weight | 0.2 kg |
Main Feature | |
Type | RJ45 port, Full duplex, MDI/MDI-X adaptive |
Port | 4 x 100M PoE ports, 1 x 100M Ethernet port |
Network Standard | IEEE802.3, IEEE802.3u, IEEE802.3x |
Data Transmission Rate | 10/100Mbps |
MAC Address Table | 1K |
Warranty | 1 Year |
-DS-3E0105P-E/M(B) is a layer 2 100M PoE switch.
-Based on wire-speed forwarding, the switch supports PoE power supply and extend mode.
-The power supply distance reaches as long as 250 m.
-It also supports prior and stable transmission of the important surveillance area video when connected to the high priority ports.
