Brand | Uniview |
Type | DVR |
Model | NVR301-08S-P8 |
Video/Audio Input | |
Analog Video Input | 1-ch, BNC |
IP Video Input | 8-ch (only IP up to 10ch) |
HDMI Output | 1024X768@60,1280X720@60,1280X1024@60, 1920X1080@50,1920X1080@60 |
VGA Output | 4k(3840×2160@30),4k(3840×2160@60),1024X768@60, 1280X720@60,1280X1024@60,1920X1080@50,1920X1080@60 |
Recording Resolution | 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
Network | |
Incoming Bandwidth | 64Mbps |
Outgoing Bandwidth | 96Mbps |
Remote Users | 128 |
Protocols | P2P, UPnP, NTP, DHCP, PPPoE |
Frame Rate | |
Audio Output | 1-ch, RCA |
Synchronous Playback | 8-ch |
Corridor Mode Screen | 3/4/5/7/9 |
Decoding | |
Decoding format | Ultra 265/H.265/H.264 |
Live View/Playback | 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
Capability | 1 x 4K@30, 2 x 4MP@30, 3 x 3MP@25, 4 x 1080P@30, 8 x 720P@30,16 x D1 |
Hard Disk | |
SATA | 2 SATA interface |
Capacity | up to 10TB for each disk |
External Interface | |
Network Interface | 1 RJ-45 10M/100M/1000M self-adaptive Ethernet Interface |
USB Interface | Front panel: 1 x USB2.0, Rear panel: 1 x USB2.0 |
Alarm In | 4-ch |
Alarm Out | 1-ch |
Supported Standard | IEEE 802.3at, IEEE 802.3af |
Interface | 8 independent 100Mbps PoE network interfaces |
Max Power | |
single port | Max 30W |
In total | Max 130W |
Supported Standard | IEEE 802.3at, IEEE 802.3af |
General | |
Power Supply | 220V AC |
Power Consumption | ≤ 9 W (without HDD) |
Working Environment | -10°C~+55°C (+14°F~+131°F), Humidity ≤ 90% RH (non-condensing) |
Dimensions (W×D×H) | 380mm ×315mm × 49.1mm(15.0″ × 12.4″ ×1.9″ ) |
Weight (without HDD) | ≤2.4kg (5.29 lb) |
Warranty | 1 Year |
-Support Ultra 265/H.265/H.264 video formats.
-8-channel input.
-Third-party IP cameras supported with ONVIF conformance: Profile S, Profile G, Profile .
- Plug & Play with 8/16 independent PoE network interfaces.
- Support HDMI and VGA simultaneous output.
- Up to 8 Megapixels resolution recording.
-2 SATA HDDs, up to 10TB for each HDD.
-ANR technology to enhance the storage reliability when the network is disconnected.
-Support cloud upgrade.
