Brand | Uniview |
Type | DVR |
Model | NVR302-32S |
Video/Audio Input | |
IP video channels (active) | 8 |
Max. Picture resolution (pixel) | UHD 8 MP (3840x2160) |
Video codec | (U-)H.265,(U-) H.264, MJPEG |
Streaming Method | Unicast / Multicast |
Max. frame rate (fps) | 1x 4K@30, 2x 4MP@30, 4x 1080p@30, 8x 720p@30 |
Bit Rate Control | CBR / VBR |
Bit Rate per channel | H.265/H.265: 128-16384Kbps |
Number of video streams | 2 (1x Main, 1x Sub) |
Max. Incoming bandwidth | 48Mbps |
Max Outgoing bandwidth | 48Mbps |
Playback simultaneously (channels) | 8 |
Features | |
Fisheye camera deworming | No |
Automatic delete files | Yes, adjustable days |
Camera title | Yes |
Privacy zones | Yes |
Motion detection | Yes |
Tampering Alarm | Yes |
Scene change (tampering) | Yes |
IVA via ONVIF Motion | No |
People counting (IVA+) | Yes |
Heatmap (IVA+) | No |
Tripwire (IVA) | Yes |
Intrusion (IVA) | Yes |
Object Appear and disappear (IVA) | No |
Fast-Moving (IVA) | No |
Crowd Gathering Estimation | No |
Loitering detection (IVA) | No |
Face detect (IVA) | Yes |
Audio detect (IVA) | Yes |
Schedule recording | Yes |
Alarm recording (dig. input) | Yes, from camera |
Motion recording | Yes |
Manual recording | Yes |
Permanent recording | Yes |
Pre-alarm recording | Ja, einstellbar bis zu 60 S. |
Post-alarm recording | Yes, adjustable up to 600 s. |
Watermark | Yes |
Intelligent search criteria | date/time, camera, alarm, motion, IVA |
Monitor notification (Popup) | Yes |
E-mail notification | Yes |
PTZ notification | Yes |
Snapshot notification | Yes |
Digital output notification | Yes, on-edge (camera) |
Password protection | Yes |
Log files | Yes |
Alarm management | HTTP, FTP, SMTP, ONVIF |
Menu languages | German, English, and others |
Max number of users | 128 |
Schedule | Yes |
Edge Recording | Local on desktop |
ANR | Yes (for records) |
UPNP support | Yes |
Camera update via recorder | Yes |
Interface | |
Number of Ethernet ports | 1 |
Ethernet connector | RJ-45 |
Ethernet standards | 10Base-TX/100Base-TX |
Ethernet speed | 10 / 100 Mbit |
Monitor outputs | HDMI (max. 4K), VGA (max. 2MP) |
Spot monitor outputs | No, simultaneous output HDMI/VGA |
Max. number of HDDs | 1 x SATA |
Max. HDD capacity | 8 TB |
Internal RAID | No |
USB interface | USB 2.0 |
USB ports | 1 x Front, 1 x Backside |
RS-232 interface | No |
RS-485 interface | No |
Control panels (external) | IR remote control / PC mouse |
Export interface | USB/network |
Audio in-/outputs | Output: 1x RCA |
Remote | |
Management software support | Many VMS |
Supported browser | Internet Explorer 11 |
P2P support | Yes (EZCloud) |
Cloud service | Yes, EZCloud UNV |
Smartphone App | EZView |
Push-Notification | Yes, via mobile app. |
Security features | HTTPS, SSL, IP Filter |
Supported protocols | P2P, UPnP, NTP, DHCP, PPPOE, SSL, TLS, SNMP, HTTPS |
Supported software standards | ONVIF, API |
ONVIF version/profile | Profile S, Profile G, C, Q, A,T |
Supported software for | remote access, Web-Plug-In, APP (iPhone, Android) |
General | |
Housing material | Aluminum / Plastic |
Voltage | 12 V DC using external power supply 230VAC/3A |
Max. Power consumption (watt) | 5W (without HDD) |
Operating temperature (°C) | -10 to +55 |
Rel. humidity (%) | Max. 90, non-condensing |
Dimensions W x D x H (mm) | 260 x 240,2 x 43,6 |
Weight | 1 Kg |
Warranty | 1 Year |
Feature:
-8-channel input.
-Third-party IP cameras supported with ONVIF conformance.
-Remote Users 128.
-Support 1-ch HDMI, 1-ch VGA, HDMI at up to 4K(3840x2160) resolution.
-HDMI and VGA simultaneous output.
-Up to 8 Megapixels resolution recording.
-1 SATA HDDs, up to 10TB for each HDD.
-Support cloud upgrade.
-Support for mobile client access.
