Brand | Hikvision |
Model | DS-9664NI-I8 |
Type | 64 Channel NVR |
Video Output (VGA) | 2K (2560 x 1440)/60Hz, 1920 x 1080p/60Hz, 1600 x 1200/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz, VGA2: 1920 x 1080p/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz |
Video Output (HDMI) | 4K (3840 x 2160)/60Hz, 4K (3840 x 2160)/30Hz, 2K (2560 x 1440)/60Hz, 1920 x 1080p/60Hz, 1600 x 1200/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz, HDMI2: 1920 x 1080p/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz |
Video Recording Res. | 12MP/ 8MP /6MP/ 5MP/ 4MP/ 3 12 MP/8 MP/6 MP /5 MP/4 MP/3 MP/ 1080p/ UXGA/ 720p/ VGA / 4CIF/ DCIF/ 2CIF/ CIF/ QCIF |
Max. Video Recording Res. | 3840 x 2160 |
IP Video Input | 64-channel, Up to 12 MP resolution |
Audio Output Channel | 2-ch, RCA (2.0Vp -p, 1KΩ) |
Two way Audio | 1-ch, RCA (2.0 Vp-p, 1kΩ) |
Live View / Playback Resolution | Up to 12 MP high-definition live view |
Decoding Capability | 2-ch-12 MP (20fps) / 4-ch-8 MP (25fps) / 8-ch-4MP (30fps) / 16-ch-1080p (30fps) |
Synchronous Playback | 16-ch |
Network Protocol | TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS |
Number HDD Interface (SATA) | 8 SATA |
Max HDD Support (GB,TB) | Up to 10TB capacity for each HDD |
Max. Storage Support | 80TB |
Network Interface (RJ45) | 2 x RJ-45 10/100/1000 Mbps self-adaptive Ethernet |
Serial Interface | RS-232; RS-485; Keyboard |
Front panel | 2 x USB 2.0; Rear panel: 1 x USB 3.0 |
Remote Connections | 128 |
Chassis | 2U |
Power Supply | 100 to 240 VAC, 50 to 60 Hz |
Power Consumption | 30 W |
Dimensions | 45 x 470 x 90mm |
Weight (Kg) | 10 kg |
IP video input | 64-ch, Incoming bandwidth: 320 Mbps, or 200 Mbps (when RAID is enabled), Outgoing bandwidth: 256 Mbps, or 200 Mbps (when RAID is enabled), |
Remote connection | 128, Recording resolution: 12 MP/ 8 MP/ 6MP/ 5MP/ 4 MP/ 3MP / 1080p/ UXGA/ 720p/ VGA/ 4CIF/ DCIF/ 2CIF/ CIF / QCIF, Array type: RAID0, RAID1, RAID5, RAID6, RAID10, Serial interface: RS-232, RS-485, Keyboard, Remote connection: 128 |
Warranty | 1 year |
- Third-party network cameras supported.
- Up to 12 Megapixels resolution recording.
- Support 2-ch HDMI, 2-ch VGA, HMDI1 at up to 4K(3840x2160) resolution.
- Up to 64 IP cameras can be connected with 320M incoming bandwidth.
- Up to 8 SATA interfaces Support.
- HDD hot swap with RAID0,1,5,6,10 storage scheme configurable.
- Support various VCA detection alarm and VCA search.
- Support H.265/H.264/MPEG4 video formats.
