| Brand | Hikvision |
| Model | DS-8632NI-K8 |
| Network | |
| Incoming bandwidth | 256Mbps |
| Outgoing bandwidth | 160Mbps |
| Video/Audio Output | |
HDMI/VGA output | 4-ch, VGA1: 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 ×1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz; HDMI1: 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560× 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 ×1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz; VGA2/HDMI2: 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 ×768/60Hz |
| Recording Resolution | 8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Synchronous Playback | 16-ch |
| Decoding | |
| Capability | 8-ch@1080P |
| Live view / Playback | 8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF |
| Hard Disk | |
| eSATA | 1 eSATA interface |
| SATA | 8 SATA interfaces for 8 HDDs |
| Capacity | Up to 6TB capacity for each HDD |
| External Interface | |
| Network Interface | RJ-45 10/100/1000Mbps self-adaptive Ethernet interfaces |
| Serial Interface | RS-232, RS-485, Keyboard |
| USB Interface | Front panel: 2 × USB 2.0 |
| Rear panel | 1 × USB 3.0 |
| Alarm In | 16-ch |
| Alarm Out | 4-ch |
| General | |
| Power Supply | 100 to 240 VAC, 50 to 60 Hz |
| Power | 200 W |
| Consumption(without hard disk and POE) | ≤ 30 W |
| Working Temperature | -10 oC ~ +55 oC (+14 oF~ + 131 oF) |
| Working Humidity | 10 % ~ 90 % |
| Chassis | 2U chassis |
| Dimensions | 445 × 470 × 90 mm (17.5" × 18.5" × 3.5") |
| Weight(without HDD) | ≤ 8 kg (17.6 lb) |
| Video/Audio Input | |
| Two-way audio input | 1-ch, RCA (2.0 Vp-p, 1kΩ) |
| IP video input | 32-ch |
| Warranty | 1year |
- VCA detection alarm is supported.
- Instant playback for assigned channel during multi-channel display mode.
- Smart search for the selected area in the video; and smart playback to improve the playback efficiency.
- Supports HDD quota and group modes; different capacity can be assigned to different channels.
