Brand | Hikvision |
Model | DS-7604NI-Q1/4P |
Type | 04 Channel (NVR) |
Video Output (VGA) | 1-ch, 1920 x 1080p/60Hz, 1600 x 1200/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz |
Video Output (HDMI) | 1-ch, 4K (3840 x 2160)/30Hz, 1920 x 1080p/60Hz, 1600 x 1200/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz |
Video Recording Res. | 8 MP/6 MP/5 MP/4 MP/3 MP/1080p /UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF |
Max. Video Recording Res. | 1920 x 1080 |
Audio Output Channel | 1-ch, RCA (Linear, 1K ohm) |
Two way Audio | 1-ch, RCA (2.0 Vp-p, 1k ohm) |
Decoding Capability | 4-ch, 1080p |
Synchronous Playback | 4-ch |
Network Protocol | TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS |
Number HDD Interface (SATA) | 1 SATA |
Max HDD Support (GB,TB) | 8TB |
Max. Storage Support | 8TB |
Network Interface (RJ45) | 1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
USB Port | 2 x USB 2.0 |
POE Interface | 4-ch |
Incoming Bandwidth | 40 Mbps |
Outgoing Bandwidth | 80 Mbps |
Chassis | 1U chassis |
Power Supply | 48 VDC, 1.35 A |
Power Consumption | <- 10 W |
Max. Power | <- 50W |
Dimensions | 320 x 240 x 48 mm |
Weight (Kg) | <- 1 kg |
Decoding Format | H.265+,H.265,H.264+,H.264, PoE Standard: IEEE 802.3 af/at, |
Working Temperature | 10 - +55 degree C, Working Humidity: 10 - 90 %, |
Warranty | 1 year |
- Supports live view, storage.
- Playback of the connected camera at up to 8 MP resolution.
- Centralized management of IP cameras.
- Including configuration, information import/export, real-time information display, two-way audio, upgrade, etc.
