Brand | WALTON |
Screen size | 1.397m |
Aspect ratio | 16:9, 4:3 |
Resolution | 3840*2160 |
Viewing angle | 1780 / 1780 |
Contrast | 1200:1 |
Basic Information | |
Product Type | LED UHD Smart ANDROID ATV |
Chassis | MT5522.81 |
CPU | CA53x4 64bit 1.008GHz |
GPU | Mali 450, 492MHz |
OS | Android 7.0 AOSP |
Memory/Flash | 1.25GByte(DDR3-1866) / 8GB EMMC |
UI Style | GAIA |
Launcher Home Pages Show | GAIA |
OSD Language | English, French, Arabic |
TV System | PAL B/G、D/K、I;NTSC-M;DVB-T/T2 |
AV System | PAL,、NTSC |
Channels | 199 |
Power Supply | AC 110V-240V 50/60Hz |
Power Consumption (TV On) | 200W |
Power Consumption(Standby) | ≤0.5W |
Certification | HDMI, Dolby, ERP |
ECO Energy efficiency | Yes |
Internet Link | wireless Wi-Fi Default |
LED Indicator Status | RED in Standby |
Basic Function | |
Initial Setup | Yes ,for user setting in TV first starting |
HDMI Auto Switch | Manual |
Channels Edit | For Channel renamed |
Input Settings | For Input source device choice |
Sleep Timer | Yes |
Wi-Fi | 802.11a/b/g/n/ac; 2.4G+5G |
BT | No |
HDR 10 | HDMI , USB |
T-Link (CEC) | Yes |
HDMI ARC | Yes |
Teletext | Yes |
S/W update | USB s/w update |
Power Label | A |
Picture | |
Picture Mode | Standard Dynamic Natural Movie Personal |
Screen Mode | 16:94:314:9CineraZoom etc. |
Noise Reduction | Low, Middle, High, Auto Off |
Backlight Adjustable | Yes (0~100) |
Color Temperature | Normal/Warm/Cool/Customer |
Gamma Adjustable | No |
Dynamic Contrast | Yes |
Over scan | Yes |
Picture Freeze | Yes |
Game Mode | No |
Film Mode | No |
Picture Reset | Yes |
Application List | |
YouTube | Pre-install, Global Online Movies |
App Store | Aptoide |
File Browser | Pre-installed |
E-Share | Yes, default on, [Wi-Fi direct] |
Browser | Webpage Browser |
Media center | Media/Music play for USB Device |
USB Device Media Format | |
Music | MP3/AC3/LPCM |
Picture | JPEG/BMP/PNG/GIF |
Multi media Video | H.264/H.265/MPEG2/M |
Signal Format Capability | |
DVI Video Format | Up to XGA for HDMI-PC |
HDMI Video Format | up to 1080P |
PC Compatibility | Yes |
Panel Specification | |
Backlight Unit | LED |
Panel supplier | LG |
Aspect Ratio | 16:9, 4:3 |
Panel Active Size (inch) | 1.397m |
Display Resolution | 3840*2160 |
Brightness (cd/m2) | 300(mini),320nits(typical) |
Contrast Ratio | 1200:1 |
Response Time (G to G) | 8ms |
Viewing Angle (H/V) | 178°/178° |
Life Time(Typ.) | 30,000hrs |
Walton Fluid Motion Engine (FME) | 120Hz |
WCG | NTSC 85% |
Terminals | |
HDMI 2.0 | 3 HDMI (include CEC, ARC) |
RJ45 | Yes |
Headphone | Yes |
Tuner | ATV/DVB-T/T2 |
SPDIF | No |
CI | No |
Sound | |
Speakers | Integrated speakers (Bottom side) |
Audio Power Output (THD=10%) | 2×10W |
Sound Preset | Standard Music, Movie, News ,Personal |
Sound Control | Five band equalizer adjust in Personal mode |
TV Placement | Desk top / Wall mount |
Essential Accessories (Default) | |
Operation Manual | English(Default) |
Remote Control and batteries | WALTON RC and AAA batteries |
Base Stand | Integrated Packaging |
AC power cord | 1 pc |
Dimensions & Weight | |
TV with Stand (L × W × H) | 1230mm x 335mm x 760mm |
TV without Stand (L × W × H) | 1230mm x 65mm x 710mm |
TV Shipping dimensions (L × W × H) | 1315mm x 145mm x 845mm |
TV with Stand Weight | 18.22 Kg |
TV without Stand Weight | 17.65 Kg |
TV Shipping Weight | 21 Kg |
Loading | |
40 HQ Container | Approx. 405 Pcs |
40 GP Container | Approx. 270 Pcs |
20 GP Container | Approx. 126 Pcs |
Warranty Information:
- TV Replacement Guarantee : 6 months (Condition Applicable)
- LED Panel: 4 Years
- Spare Parts: 2 Years
- Free Service: 5 Years
