Brand | WALTON |
TV System | PAL ; NTSC ; SECAM |
Receiving Range | 48.25MHz – 863.25 MHz |
No of Channel (ATV) | 199 |
Power Supply | AC 110V-240V 50/60Hz |
Power Consumption (TV On) | 75W |
Power Consumption (STB) | < 0.5 W |
Hardware Configuration | |
CPU | Quad Core A53 |
GPU | Mali 450*2 |
CPU Frequency | 804 MHz |
GPU Frequency | 432 MHz |
DDR RAM Size | 1GB |
eMMC Flash | 8 GB |
Software Configuration | |
OS | Android 7.0 (AOSP) |
Apps Store | Yes |
E-Share + Screen Mirroring | Yes ( Screen Mirroring Performance can vary upon device to device ) |
Wi-Fi Hotspot | Yes |
Task Manager | Yes |
HDMI (CEC, ARC) | Yes |
Panel Specification | |
Backlight Unit | ELED |
Panel Supplier | Auto |
Aspect Ration | 16:9 |
Panel Size ( inch ) | 1.09 m |
Display Resolution | 1920 X 1080 |
Brightness | 320 cd/m2 (typical) |
Contrast Ratio | 3000:1 (typical) |
Response Time | 8 ms (typical) |
Viewing Angle | 178° / 178° |
Color | Black, Silver |
Refresh Rate | 60 Hz |
Sound | |
Audio Power Output | 2 X 8 Watt |
Sound Mode | Standard, Music, Theater, News, User |
Sound Control | 2 Ch Speaker System |
Surround Sound | Yes |
Bottom Terminals | |
RJ45 ( LAN Port ) | 1 |
VGA | 1 |
PC Audio In | 1 |
AV and YPbPr Audio | 1 |
CVBS In &YPbPr In | 1 |
RF In | 1 |
AUDIO Out | 1 |
Side Terminals | |
HDMI In | 3 |
USB 2.0 | 2 |
Optical Out (Audio) | 1 |
Device Media Format | |
Music | MP3; WAV; MKA/AAC |
Picture | JPG/JPEG/BMP/PNG |
Video | AVI; MP4; TS/TRP; MPG; MKV; MOV; DAT; VOB; RM/RMVB |
Text | TXT |
Subtitle | SRT; .SUB; .SMI |
Dimensions & Weight | |
TV with Stand (L × W × H) | 1015mm × 195mm × 600mm |
TV without Stand (L × W × H) | 960mm × 40mm × 575mm |
TV Shipping dimensions (L × W × H) | 1080mm × 155mm × 710mm |
TV with Stand Weight | 10.2 KG |
TV without Stand Weight | 9.88 KG |
TV Shipping Weight | 14.10 KG |
Loading | |
40 HQ Container | Approx. 450 Pcs |
40 GP Container | Approx. 450 Pcs |
20 GP Container | Approx. 222 Pcs |
Warranty Information:
– TV Replacement Guarantee : 6 months (Condition Applicable)
– LED Panel: 4 Years
– Spare Parts: 2 Years
– Free Service: 5 Years
Note:
This warranty does not cover any damage due to accident, electricity fault, natural causes or negligence. And Authority keeps the power to change, expend, correction, stop or cancel the warranty period without any prior notice.
