Brand | Walton |
Type | Generator |
Model | Proxima 2200E |
Start | |
Starting System | Electric & Recoil Start |
Fuel | |
Fuel Tank capacity | 15 L |
Fuel Option | Petrol/Octane |
Fuel Consumption | 1.2 L/Hr. at rated load |
Time | |
Operating Time | 6 Hours Continuously at rated load |
Engine | |
Engine Type | Single cylinder; 4-stroke gasoline engine |
Engine Displacement | 208 cc |
Cooling System | Air cooling |
Engine power | 6.5 hp |
Shaft position | Horizontal shaft |
Engine oil capacity | 0.5 L |
Ignition | Transistorized Magneto |
Load Capacity | |
Maximum Output Capacity | 2200 Watt |
Rated Output Capacity | 2000 Watt |
Frequency | |
Frequency in hertz | 50 Hz |
Voltage | |
Rated output voltage | 230V |
Noise | |
Noise Level (dB) at rated load | 75 decibel at 3m distance |
Speed | |
Speed per minute | 3000 RPM |
Carton Dimension (mm) | |
Length | 675 mm |
Width | 465 mm |
Height | 468 mm |
Product Dimension (mm) | |
Length | 593 mm |
Width | 445 mm |
Height | 457 mm |
Weight (kg) | |
Gross Weight | 47 kg |
Net Weight | 50 kg |
Features:
- Noncontact transistor ignition system.
- Automatic voltage regulator (AVR).
- Frequency: 50 Hz.
- Max. AC output power: 2.2 KW.
- Rated output power: 2.0 KW.
- Operating time: 6 hours continuous at rated load.
Warranty Information:
- Engine: 1 Year
- Engine Spare Parts:1 Year
- After Sales Service:1 Year
Note:
- This warranty does not cover any damage due to accident, electricity fault, natural causes or negligence.
- Authority keeps the power to change, expend, correction, stop or cancel the warranty period without any prior notice.
