Brand | WALTON |
Type | Direct Cool |
Door | Glass Door |
Refrigerant | R600a |
Special Technology | Nano Health care |
Wide Voltage Design | (140V-260V) |
Capacity | |
Gross Volume | 348 Ltr |
Net Volume | 333 Ltr. |
Performance | |
Climate Type (SN, N, ST, T) | N~ST |
Rated Voltage/ Hz | 220-240V~ and 50Hz |
Compressor Input Power (Watt) | V 0201- 145.7, V 0301- 115, V 0302- 115 |
Compressor Type | V 0201- RSCR, V 0301- RSIR, V 0302- RSIR |
Cooling Effect | Freezer Cabinet Less than -18 ̊C ,Refrigerator Cabinet 0 ̊C to +5 ̊C |
General features | |
Temperature Control (Electronic/ Mechanical) | Mechanical |
Defrosting (Automatic/ Manual) | Manual |
Reversible Door | No |
Handle (Recessed/ Grip) | Recessed/Grip |
Lock | Yes |
Refrigerant | V 0201- R600a, V 0301- R600a, V 0302- R600a. |
Condenser | V 0201- MS, V 0301- MS, V 0302- MS. |
Capillary | Copper |
Polyurethane foam blowing agent | Encyclopedic [Eco-friendly (100% CFC & HCFC Free) Green Technology] |
Operating voltage | V 0201/0301/0302: Wide Voltage Design (140V-260V) |
Refrigerator Compartment | |
Shelf (Material/ No.) | Wire/3 |
Door Basket | 4 |
Interior Lamp | Yes |
Vegetable Crisper | Yes |
Vegetable Crisper Cover | Yes(Glass/ Plastic) |
Egg Tray or Pocket | Yes/2 |
Can Storage Dispenser | No |
Deodorizer | No |
Freezer Compartment | |
Shelf (Material/ No.) | Wire/ 2 |
Drawer | No |
Door Basket | No |
Interior Lamp | No |
Net Dimensions | |
Width/mm | 650 |
Depth/mm | 645 |
Height/mm | 1740 |
Packaging Dimensions | |
Width/mm | 710 |
Depth/mm | 710 |
Height/mm | 1790 |
Weight/Kg - Net/Packing | 66/ 73 ± 2 |
Loading Capacity- 40HQ/ 40Ft/ 20Ft | 67/ 48/ 24 |
Star rating (BDS 1850:2012) | 5 |
Residential Use:
- Replacement Guarantee: 1 Year (Condition Apply)
- Main Parts (Compressor): 12 Years
- Spare Parts: 4 Years *
- After Sales Service:5 Years *
Commercial Use:
- Main Parts (Compressor): 4 Years
- Spare Parts: 2 Years *
- After Sales Service: 2 Years *
Note:
This warranty does not cover the following cases:
1. Any damage due to accident, electrical fault, natural causes, negligence or improper installation.
2. Any damage or failure caused by unauthorized modification or alteration.
3. Products with original serial numbers that have been removed, distorted or cannot be readily recognized.
