| Brand | WALTON |
| Type | Direct Cool |
| Capacity | |
| Gross Volume | 268 Ltr. |
| Net Volume | 254 Ltr |
| Net Weight | 61 ± 2 Kg |
| Gross Weight | 66 ± 2 Kg |
| Performance | |
| Climate Type (SN, N, ST, T) | N~ST |
| Rated Voltage/ Hz | 220 ~ 240/ 50 |
| Compressor Input Power (Watt) | V 02.01-132, V 03.01-118, V 03.02-118, V 04.01-127 |
| Compressor Type | V 02.01-RSCR, V 03.01-RSCR, V 03.02-RSCR, V 04.01-RSCR |
| Cooling Effect | Freezer Cabinet Less than -18 ̊C ,Refrigerator Cabinet 0 ̊C to +5 ̊C |
| Energy Rating | 5 star (BDS 1850:2012) |
| General features | |
| Temperature Control (Electronic/ Mechanical) | Mechanical |
| Defrosting (Automatic/ Manual) | Manual |
| Reversible Door | No |
| Handle (Recessed/ Grip) | Recessed/ Grip |
| Condenser | Copper |
| Lock | Yes |
| Refrigerant | V 02.01-R134a, V 03.01-R600a, V 03.02-R600a, V 04.01-R600a |
| Thermostat | RoHS Certified |
| Capillary | Copper |
| Polyurethane foam blowing agent | Cyclopentene [Eco-friendly (100% CFC & HCFC Free) Green Technology] |
| Recommended voltage stabilizer capacity | V 02.01-1000V V 03.01,V 03.02-Low Voltage(140~260V) For V 03.01,V 03.02 - Wide Voltage Range (140Vac - 260Vac).Voltage stabilizer is not required. In case of voltages beyond this range, 1000VA is recommended. V 04.01-Low Voltage(150~260V). For V 04.01 - Wide Voltage Range (150Vac - 260Vac). Voltage stabilizer is not required. In case of voltages beyond this range, 1000VA is recommended. |
| Refrigerator Compartment | |
| Shelf (Material/ No.) | Wire/3 |
| Door Basket | GPPS/4 |
| Interior Lamp | Yes |
| Vegetable Crisper | Yes |
| Vegetable Crisper Cover | Yes |
| Egg Tray or Pocket | Yes |
| Freezer Compartment | |
| Shelf (Material/ No.) | Wire/3 |
| Drawer | HIPS/5 |
| Door Basket | No |
| Interior Lamp | No |
| Net Dimensions | |
| Width/mm | 545 mm |
| Depth/mm | 630 mm |
| Height/mm | 1800 mm |
| Packaging Dimensions | |
| Width/mm | 580 mm |
| Depth/mm | 640 mm |
| Height/mm | 1810 mm |
| Loading Capacity- 40HQ/ 40Ft/ 20Ft | 97/ 72/ 36 |
Residential Use:
- Replacement Guarantee: 1 Year (Condition Apply)
- Main Parts (Compressor): 12 Years
- Spare Parts: 4 Years *
- After Sales Service:5 Years *
Commercial Use:
- Main Parts (Compressor): 4 Years
- Spare Parts: 2 Years *
- After Sales Service: 2 Years *
