Brand | WALTON |
Type | Direct Cool |
Capacity | |
Gross Volume | 213Ltr. |
Gross Weight | 52 ± 2 Kg |
Net Volume | 176Ltr. |
Net Weight | 48.5 ± 2 Kg |
stabilizer capacity | If out of voltage range(140V-260V), then suggested voltage stabilizer capacity is 1000VA. |
Performance | |
Climatic Type (SN, N, ST, T) | N~ST |
Rated Voltage/ Hz | 220-240V/50Hz |
Compressor Input Power (Watt) | V 1001- 119,V 1002- 119,V 1101- 102,V 1102- 102,V 1201- 109,.V 1301- 108.6,V 1302- 108.6 |
Compressor Type | RSCR |
Refrigerant | V 1001- R134a,V 1002-R134a,V 1101- R600a,V 1102- R600a,V 1201-R134a,V 1301-R600a,V 1302-R600a,V 1401-R600a |
Condenser | V 1001- Copper,V 1002-Copper,V 1101- Copperm,V 1102- Copper,V 1201-Copper,V 1301-Copper,V 1302-CopperV 1401-MS |
Cooling Effect | |
Freezer Cabinet | Less than -18℃ |
Refrigerator Cabinet | 0℃ to +5℃ |
General Features | |
Temperature Control | Mechanical |
Defrosting | Manual |
Handle | Recessed/ Grip |
Lock | Yes |
Capillary | Copper |
Refrigerator Compartment | |
Shelf (Material/ No.) | Wire/2 |
Door Basket | GPPS/3 |
Interior Lamp | Yes |
Vegetable Crisper | Yes |
Vegetable Crisper Cover | Yes |
Egg Tray or Pocket | Yes |
Freezer Compartment | |
Shelf (Material/ No) | Wire/2 |
Dimensions (Net) | |
Width/mm | 542 |
Depth/mm | 618 |
Height/mm | 1500 |
Packing | |
Width/mm | 580 |
Depth/mm | 645 |
Height/mm | 1530 |
Loading Capacity- 40HQ/ 40Ft/ 20Ft | 102/ 102 /50 |
Residential Use:
- Replacement Guarantee: 1 Year (Condition Apply)
- Main Parts (Compressor): 12 Years
- Spare Parts: 4 Years *
- After Sales Service:5 Years *
Commercial Use:
- Main Parts (Compressor): 4 Years
- Spare Parts: 2 Years *
- After Sales Service: 2 Years *
Note:
This warranty does not cover the following cases:
1. Any damage due to accident, electrical fault, natural causes, negligence or improper installation.
2. Any damage or failure caused by unauthorized modification or alteration.
3. Products with original serial numbers that have been removed, distorted or cannot be readily recognized.
*Authority keeps the right to change, extend, correct, stop or cancel the warranty period without any prior notice.
*This warranty covers only manufacturing defects in products & workmanship, subject to verification by company personnel.
