Brand | MSI |
Chipset | AMD Radeon |
Chipset Model | Radeon RX 6900 XT |
Model | MSI Radeon RX 6900 XT GAMING Z TRIO 16G |
Technical Information | |
CUDA Core / Stream Processors | 5120 |
Engine Clock | Boost-2425MHz, Game-2235MHz |
Boost Engine Clock Speed | 2425MHz |
Memory Clock | 16Gbps |
Capacity (GB/TB) | 16GB |
Memory Bus | 256-bit |
Memory Type | GDDR6 |
Interface(s) | PCI Express 4.0 |
DirectX Support | 12 |
OpenGL Support | 4.6 |
HDCP Support | Yes |
Supported Operating System | Windows 11 / 10 / 8 / 7 / Vista / XP |
Display & Resolution | |
Graphics Resolution Max | 7680 x 4320 |
Multi Display Capability | Quad Display |
Ports | |
HDMI Port | 1 |
Display Port | 3 |
Power | |
Power Consumption | 300W |
Recommended PSU | 850W |
Power Connectors | 8-pin x 3 |
Physical Description | |
Card Dimension | 324 x 141 x 55mm |
Cooling Fan | Triple |
Lighting | RGB |
RGB Effects | RGB |
Warranty | |
Warranty | 3 Year (No warranty for Mining) |
Additional Info | |
Others | DisplayPort Version: 1.4a, HDMI Version: 2.1, WEIGHT: 1581gm, MULTI-GPU TECHNOLOGY: Yes, VR READY: Yes, AFTERBURNER OC: Yes |
Specialty | the perfect balance between cool temperatures and quiet fans during endless gaming sessions, TORX FAN 4.0, A masterpiece of teamwork, fan blades work in pairs to create unprecedented levels of focused air pressure, Airflow Control, Don`t sweat it, Airflow Control guides the air to exactly where it needs to be for maximum cooling, Core Pipe, Precision-machined heat pipes ensure max contact and spread heat along the full length of the heatsink, Zero Frozr, Zero Frozr is the calm before the storm, keeping fans still and maintaining silence until cooling is needed, Aluminum Backplate, Thermal pads beneath the sturdy metal backplate provide additional cooling, Mystic Light, Mystic Light gives you complete control of the RGB lighting for MSI devices and compatible RGB products, MSI Center, The exclusive MSI Center software lets you monitor, tweak and optimize MSI products in real-time. |
