PRODUCT DETAILS
Brand | Cooler Master |
Model | Cooler Master MasterLiquid ML240 Illusion |
Cooler Type | Liquid CPU Cooler |
Series | MasterLiquid |
Part No | MLX-D24M-A18P2-R1 |
Fan Details
|
|
Number of Fans | 2
|
Fan Speed | 1800 RPM |
Fan Noise Level | 6 - 30 DBA |
Fan Air Flow | 47.2 (MAX) |
Fan Air Pressure | 1.60mm H2O (MAX) |
Fan Power Connector | 4-Pin (PWM) |
Fan Rated Current | 0.25A |
Fan Rated Voltage | 12VDC |
Fan Dimensions | 120 x 120 x 25 mm |
Heat Sink & Radiator Details
|
|
Radiator Material | Aluminium |
Dimension (Heat Sink/Radiator) | 277 x 119.6 x 27.2mm (Radiator) |
Tube & Pump Details
|
|
Pump Noise Level | < 10 DBA |
Pump Connector | 3-Pin |
Pump MTTF | 70,000 Hours |
Pump Power Consumption | 2.36 W |
Pump Dimensions | 81.4 x 76 x 57.8mm |
Technical Information
|
|
LED Color | ARGB |
PWM Mode | Yes |
MTTF | 160,000 Hours (Fan Life Expectancy) |
Supported CPU Socket Brand | Intel & AMD |
Supported Socket | LGA2066, LGA2011-V3, LGA2011, LGA1700, LGA1200, LGA1151, LGA1150, LGA1155, LGA1156, AM4, AM3+, AM3, AM2+, AM2, FM2+, FM2, FM1 |
Physical Description
|
|
Body Color | Black |
Warranty
|
|
Warranty | 3 year |
Additional Info
|
|
Specialty | The MasterLiquid ML-Illusion series redefines
lighting visuals with all new design features to the MasterLiquid
Series. Addressable Gen 2 RGB LEDs integrated into the all new
translucent pump, the color options are spectacularly customizable. The
Illusion is not only elegant, but extremely capable as well, featuring
the 3rd generation Dual Chamber Pump for excellent cooling performance. |
Others
| Fan Speed: 650-1800 RPM + - 10%, Radiator Size: 240 |
Cooler Master MasterLiquid ML240 Illusion ARGB Black Liquid CPU Cooler
Brand - Cooler Master, Model - Cooler Master MasterLiquid ML240
Illusion, Cooler Type - Liquid CPU Cooler, Series - MasterLiquid, Number
of Fans - 2, Fan Speed - 1800 RPM, Fan Noise Level - 6 - 30 DBA, Fan
Air Flow - 47.2 (MAX), Fan Air Pressure - 1.60mm H2O (MAX), Fan Power
Connector - 4-Pin (PWM), Fan Rated Current - 0.25A, Fan Rated Voltage -
12VDC, Fan Dimensions - 120 x 120 x 25mm, Radiator Material - Aluminium,
Dimension (Heat Sink/Radiator) - 277 x 119.6 x 27.2mm (Radiator), Pump
Noise Level - < 10 DBA, Pump Connector - 3-Pin, Pump MTTF - 70,000
Hours, Pump Rated Voltage - 12 VDC, Pump Power Consumption - 2.36 W,
Pump Dimensions - 81.4 x 76 x 57.8mm, LED Color - ARGB, PWM Mode - Yes,
MTTF - 160,000 Hours (Fan Life Expectancy), Supported CPU Socket Brand -
Intel & AMD, Supported Socket - LGA2066, LGA2011-V3, LGA2011,
LGA1700, LGA1200, LGA1151, LGA1150, LGA1155, LGA1156, AM4, AM3+, AM3,
AM2+, AM2, FM2+, FM2, FM1, Body Color - Black, Specialty - The
MasterLiquid ML-Illusion series redefines lighting visuals with all new
design features to the MasterLiquid Series. Addressable Gen 2 RGB LEDs
integrated into the all new translucent pump, the color options are
spectacularly customizable. The Illusion is not only elegant, but
extremely capable as well, featuring the 3rd generation Dual Chamber
Pump for excellent cooling performance., Others - Fan Speed: 650-1800
RPM + - 10%, Radiator Size: 240, Part No - MLX-D24M-A18P2-R1, Warranty -
3 Year.
